genius irreversible actuator compas 24 24v 6170195 (ex code 6170135)
Brand: GENIUS
SKU: 6170195
£281.52 |
|---|
GENIUS - 24V IRREVERSIBLE SWING GATE ACTUATOR FOR LEAVES UP TO 2.5M FOR RESIDENTIAL USE
- EQUIPPED WITH ENV (VIRTUAL ENCODER) FUNCTION
- ROTARY RELEASE AND CUSTOM KEY ACCESS
- INTEGRATED ADJUSTABLE MECHANICAL LIMIT SWITCHES ON OPENING AND CLOSING
- ALLOWS INSTALLATION EVEN ON LARGE PILLARS
LEAF WEIGHT IS BASED ON LENGTH, FOR LEAVES M 2.5 MAX, KG 200, FOR LEAVES M 1 MAX, KG 310
WITH LEAVES OVER 2M IT IS MANDATORY TO INSTALL THE ELECTRIC LOCK IN ORDER TO ENSURE PROPER LOCKING OF THE LEAF
GENIUS - COMPAS 24
6170195 (ex code 6170135)
TECHNICAL FEATURES:
POWER SUPPLY (V) 230
ELECTRIC MOTOR (V) 24
NOMINAL POWER (W) 50
MAX COUPLE.. (NM) 300
ANGULAR SPEED (°/SEC) 8,5
MAX LEAF WEIGHT (KG)¹ 350
MAX. CYCLES. CONSECUTIVE 30
OPERATING FREQUENCY AT 20°C CONTINUOUS
TEMP. OF OPERATION (°C) -20 +55
DEGREE OF PROTECTION IP44.
