CAME - BELT GUIDE L = 3.02 M.
MAX DOOR HEIGHT: BC = 2.4 M BM = 2.25 M STA = 2.1 M STB = 2.2 M.

001V0685

NOTES
BC = Counterweighted overhead garage door - BM = Spring-balanced overhead garage door - STA = Type A sectional door - STB = Type B sectional door
