came 2 x gearmotor ati 230v 001a3000 a3000
Brand: CAME
SKU: 001A3000 2
£1,212.00 £678.72VAT INCLUDED |
|---|
came 2 x gearmotor ati 230v 001a3000 a3000
CAME - 2 IRREVERSIBLE GEARMOTORS FOR SWING GATES UP TO 3 METERS PER LEAF
OPENING TIME OF THE LEAF 90°: 19 - 32 SECONDS
CURRENT DETECTION OF THE OBSTACLE
EQUIPPED WITH MICRO OF OPENING LIMIT SWITCH
SOLUTION FOR RESIDENTIAL AND CONDOMINIUM APPLICATIONS
POWER SUPPLY: 230V AC
( 2 PIECES )
2 x 001A3000 A3000
230V AC
| Type | A3000/A3100 A5000/A5100 | A3006/3106 A5006/A5106 | A3024N A5024N | |
| Protection level | IP44 | |||
| Power supply | 230V 50/60 Hz | 230V 50/60 Hz/24V D.C. | ||
| Motor power supply | 230V 50/60 Hz | 24V D.C. | ||
| Absorption | 1,2A | 10A max | ||
| Nominal power | 150W | 120W | ||
| Duty cycle | 50% | intensive duty | ||
| Thrust | 400-3000N | |||
| Motor's heat protection | 150°C | |||
| Maneuvering time (90°) | 19-32s | 28-45s | adjustable | |
| Operating temperature | -20 °C min +55 °C max | |||
Complementary accessories (not included):
- ZA3P: Multifunctional control panel with built-in radio decoding
- LOCK81: Single cylinder electric lock
- LOCK82: Double cylinder electric lock
- D001: Lock cylinder with din key
- H3000: Case for remote release with customized key, pull-cord handle and control button. Cord length L=5m
